The Aurora XT range is designed for users looking for seamless integration with the Thermo Scientific EASY-Spray and/or Nanospray Flex sources, particularly when column heating is required.

Is the Aurora XT compatible with your workflows?

We recommend choosing the Aurora XT if:
  1. You're using Thermo EASY-Spray or Thermo Nanospray Flex ion sources.
  2. You wish to heat your column using the HeatSync™ 2-Channel Controller or IonOpticks Heater Controller (Original).
Other compatible configurations include:
  1. Compatible with the Newomics UniESI source for use with Agilent or other instrument configurations.



Aurora XT product range dimensions include:


Aurora Frontier 60x75 XT
  1. Dimensions: 60cm x 75µm ID, 1.7µm C18
  2. Volume: 2.65μl
  3. Part No. AUR4-60075C18-XT

Aurora Ultimate 25x75 XT
  1. Dimensions: 25cm x 75µm ID, 1.7µm C18
  2. Volume: 1.1μl
  3. Part No. AUR4-25075C18-XT

Aurora Ultimate 25x150 XT
  1. Dimensions: 25cm x 150µm ID, 1.7µm C18
  2. Volume: 4.42μl
  3. Part No. AUR4-250150C18-XT

Aurora Elite 15x75 XT
  1. Dimensions: 15cm x 75µm ID, 1.7µm C18
  2. Volume: 0.66μl
  3. Part No. AUR4-15075C18-XT

Aurora Elite 15x150 XT
  1. Dimensions: 15cm x 150µm ID, 1.7µm C18
  2. Volume: 2.66μl
  3. Part No. AUR4-150150C18-XT

Aurora Rapid 8x75 XT
  1. Dimensions: 8cm x 75µm ID, 1.7µm C18
  2. Volume: 0.35μl
  3. Part No. AUR4-8075C18-XT

Aurora Rapid 8x150 XT
  1. Dimensions: 8cm x 150µm ID, 1.7µm C18
  2. Volume: 1.4μl
  3. Part No. AUR4-80150C18-XT



The following applies to all column dimensions:

Column format:
Analytical column
Column type:
Reversed-phase
For use with:
UHPLC
Pore size:
120Å
Max pressure:
>1700 bar
Temp limits:
60°C (low pH)
Particle size:
1.7μm
pH stability:
1-8
Stationary phase:
C18
