Aurora column details

Aurora column details

The Aurora columns are suited to users operating with the Thermo Scientific Nanospray Flex source, particularly in workflows where column heating is not required or where a third-party heating system is already in use (e.g., Sonation Column Oven).

Is the Aurora compatible with your workflows?

We recommend choosing the Aurora if:
  1. You're using the Thermo Nanospray Flex ion source, and
  2. You either don’t require column heating, or are using an alternative heating system (e.g., Sonation Column Oven).




Aurora columns are available in the following dimensions:


Aurora Frontier 60x75
  1. Dimensions: 60cm x 75µm ID, 1.7µm C18
  2. Volume: 2.65μl
  3. Part Nos. AUR4-60075C18

Aurora Ultimate 25x75
  1. Dimensions: 25cm x 75µm ID, 1.7µm C18
  2. Volume: 1.1μl
  3. Part Nos. AUR4-25075C18

Aurora Ultimate 25x150
  1. Dimensions: 25cm x 150µm ID, 1.7µm C18
  2. Volume: 4.42μl
  3. Part Nos. AUR4-250150C18

Aurora Elite 15x75
  1. Dimensions: 15cm x 75µm ID, 1.7µm C18
  2. Volume: 0.66μl
  3. Part Nos. AUR4-15075C18

Aurora Elite 15x150
  1. Dimensions: 15cm x 150µm ID, 1.7µm C18
  2. Volume: 2.66μl
  3. Part Nos. AUR4-150150C18

Aurora Rapid 5x150
  1. Dimensions: 5cm x 150µm ID, 1.7µm C18
  2. Volume: 0.88μl
  3. Part Nos. AUR4-50150C18

Aurora Rapid 5x75
  1. Dimensions: 5cm x 75µm ID, 1.7µm C18
  2. Volume: 0.22μl
  3. Part Nos. AUR4-5075C18


The following applies to all column dimensions:


Column format:
Analytical column
Column type:
Reversed-phase
For use with:
UHPLC
Pore size:
120Å
Max pressure:
>1700 bar
Temp limits:
60°C (low pH)
Particle size:
1.7μm
pH stability:
1-8
Stationary phase:
C18
